Double Acting Cylinder
Trunnion Mounting Cylinder
Body-mounted trunnion pins give a stable pivot for angular motion. Common on booms and tilting frames.
- Bore Diameter 50 mm to 1000 mm
- Piston Rod Diameter 30 mm to 900 mm
- Working Pressure Up to 350 bar
- Test Pressure 1.5 × working pressure
Specifications
| Bore Diameter | 50 mm to 1000 mm |
|---|---|
| Piston Rod Diameter | 30 mm to 900 mm |
| Stroke Length | Up to 6000 mm, application dependent |
| Working Pressure | Up to 350 bar |
| Test Pressure | 1.5 × working pressure |
| Mounting | Intermediate or rear trunnion |
| Seal Material | Polyurethane / Nitrile, field replaceable |
| Cylinder Tube | Honed steel tube, H8 tolerance |
| Piston Rod | Hard chrome plated, f7 tolerance |
| Operating Temperature | -20 °C to +100 °C |
About this product
Trunnion Mounted Hydraulic Cylinders feature mounting pins (trunnions) welded or bolted to the cylinder body, providing a fixed pivot axis around which the entire cylinder can swing. This design allows the cylinder to accommodate angular movement during operation while maintaining secure attachment to the machine frame.
The trunnion mount is particularly effective in applications where the cylinder must pivot through a significant arc — such as excavator booms, crane jibs, and industrial machinery with rotating components. By allowing the cylinder body itself to swing, trunnion mounting eliminates the bending stresses that would otherwise develop in the rod and seals.
KBR Engineers manufactures trunnion cylinders with precision-machined trunnion pins, reinforced mounting lugs, and high-quality bearings or bushings. Trunnion positions can be configured at the center, head, or cap end of the cylinder to suit different mechanical linkage requirements.
Every trunnion cylinder is manufactured with precision-honed barrels, chrome-plated piston rods, premium sealing systems, and undergoes complete pressure and function testing before dispatch.
Manufacturing Range
KBR Engineers manufactures a wide range of custom-built hydraulic cylinders to meet diverse industrial requirements. We offer cylinder bore sizes from 50 mm to 1000 mm and piston rod diameters from 30 mm to 900 mm. All cylinders are designed and manufactured using high-quality materials, precision machining, and advanced sealing technology to ensure reliable performance, durability, and long service life.
Features
High Pressure
Rated up to 350 bar working pressure.
Precision Honed
H8 tolerance bore finish for even seal wear.
Pressure Tested
Every unit tested at 1.5× working pressure before dispatch.
Heavy Load Pivot
Body-mounted trunnion pins carry boom and tilt-frame loads.
Applications
- Construction Equipment
- Material Handling
- Steel & Cement Plants
- Agriculture
- Mining
- Hydraulic Presses
