Hydraulic Power Pack Unit
Hydraulic Power Pack Unit
Pump, motor, valving and reservoir on one frame, sized to your pressure and flow. Electric, diesel or PTO drive.
- Working Pressure Up to 350 bar
- Test Pressure 1.5 × working pressure
- Seal Material Nitrile, pump and valve seals
- Operating Temperature -10 °C to +80 °C reservoir
Specifications
| Working Pressure | Up to 350 bar |
|---|---|
| Test Pressure | 1.5 × working pressure |
| Mounting | Skid-mounted, portable or custom base frame |
| Seal Material | Nitrile, pump and valve seals |
| Operating Temperature | -10 °C to +80 °C reservoir |
About this product
Hydraulic Power Pack Units are the central power source for any hydraulic system, generating and delivering pressurized hydraulic fluid to drive cylinders, motors, and other actuators. A power pack combines a prime mover (electric motor or diesel engine), hydraulic pump, reservoir, filtration system, valves, and controls into a self-contained unit.
KBR Engineers designs and manufactures hydraulic power packs for a wide range of applications — from compact mini units for single-cylinder operations to large industrial systems powering multiple actuators simultaneously. Each unit is engineered for the specific pressure, flow rate, and duty cycle requirements of your application.
Our power packs feature high-efficiency pumps (gear, vane, or piston type), quality electric motors or engine drives, precision directional and pressure control valves, robust steel reservoirs with proper baffling and filtration, and comprehensive safety features including pressure relief, temperature monitoring, and level indicators.
Every power pack is fully assembled, filled, tested, and calibrated in our facility before dispatch. We provide complete hydraulic circuit design, component selection, and system commissioning support.
Manufacturing Range
KBR Engineers manufactures hydraulic power pack units in various capacities and configurations. From compact mini power packs (0.5 HP) to heavy-duty industrial units (200+ HP), each unit is designed to deliver the exact pressure and flow rate required for your application. We offer electric motor-driven, diesel engine-driven, and PTO-driven configurations with reservoir capacities from 10 litres to 5000+ litres.
Features
Integrated Design
Pump, motor, reservoir and valving assembled on one frame.
Custom Reservoir
10 L to 500 L capacity, mild steel or stainless.
Filtration Included
Return-line and suction filters fitted as standard.
Quiet Operation
Acoustic enclosure option for indoor installations.
Applications
- Industrial Machinery
- Hydraulic Presses
- Material Handling
- Construction Machinery
- Mining
- Factory Automation
